Best portable ultrasound units-MSLPU06
MSLPU06 Best portable ultrasound units
1.Full digital ultrasound scanner
2. Laptop ultrasound scanner
3. portable ultrasound scanner
best portable ultrasound units MSLPU06 Advantages:
Light weight of 1 kg, 2cm for thickness, 17cm for width, 25cm for length, very convenience for doctors to carry out.
U Disk for upgrade.
Dismountable battery.
Connect with Jet printer, Laser printer to print directly.
Other performance is as the same as the laptop computer, such as power save mode, touch mouse and so on.
Portable ultrasound units MSLPU06 Features:
Battery
192-frame cineloop
Two USB ports
SD card
General software, Obstetrics software and Cardiac software.
buy best portable ultrasound units MSLPU06 Software:
General measurement: distance, circumference, volume, angle, heart rate and etc.
Obstetrics measurement software: BPD, GS, CRL, AD, AC, FL, HC, FTA, APTD, TTD and calculating fetus’ weight, pregnancy week, fetal physiological rating according to the previous measurements.
Cardiac measurement software. The measurement result could be shown automatically.
Best portable ultrasound MSLPU06 detail drawings
portable ultrasound unit MSLPU06 Specifications：
Scanning mode
electronic linear array, electronic convex array
Imaging model
B (B-mode Ultrasound Imaging (The Definition of B Mode Ultrasound )), B/B, B/M, M (M Mode Ultrasound Definition), 4B
Gray scale
256 levels, four selectable gamma curve
Transducer frequency
2.5-8.5 MHz
Magnification
×0.8, ×0.9, ×1.0,×1.1,×1.2,×1.3, ×1.4,×1.5
Permanent storage
1024
Cine loop
192, manual and automatic
Sound Power
8 grades from 0-7
Dynamic Range
Adjustable from 30-75
USB Ports
2
IP set
8
Body Mark
35 kinds
Pseudo color
5 kinds
Image Processing
Up/Down, Left/Right, Black/White, Frame correlation
Edge enhancement, Scroll
Measurement
Circumference, Area, Volume, Heart ratio, Velocity,
OB and Cardiac
Focus
Number and location of the focus can be adjusted
Puncture
Puncture guide line
TGC
Adjustable, Near field, Middle field and Far field are
adjustable from 39-99
Body Marks
35
IP set
Hospital’s name, Date, Time, Formula of Fetus’
weight and Pseudo color
Image store format
BMP, DICOM
Formula of Fetus’ weight
OSAKA, TOKYO1, TOKYO2, MERZ
Frame correlation, Edge enhancement, Dynamic
range, center line, scan angle Puncture
Voltage
AC85V-265V
