High Frequency X-ray Radiolography System MSLHX02 for sale

High Frequency X-ray Radiography System MSLHX02:

Table side adjustment, Remote-control Exposure
Excellent X-ray Source, Low skin dose
1.Table side human graphic color LCD touch screen for parameters setting ,together with
the remote control exposure method make the operating much safer and convenient .
2.Adopt technology of kV closed-loop control and mAs digital closed-loop control to
ensure the accuracy and reproducibility of the x-ray dose.
3.High frequency high voltage x-ray generator and high frequency inverter power make
excellent X-ray source, low skin dose and sharp image.

Features:

1.Multi body parts, multi position photography parameters for adult and children have been preprogrammed. Easy to learn and operate even to new operators
2.The compact design of the Xx-ray monoblock make it much easier to install.
3.Self-protection and faultcode alarming function for much safer operate.
4.The table can float freely, electromagnetic brake to make the photography position more accuracy.
5.Standard: Bucky Stand: used for the vertical photography of head, chest, pelvis, limbs and so on.
6.Standard: human graphical LCD touch screen control console makes compartment photography be possible.

Technical Parameters:

Item :MSLHX02
Power Output :25kW
Tube Voltage:40~125kV
Tube Current:200mA
Inverter Frequency:40kHz
Power supply:380V,50Hz,Capacity≥40kVA
mAs :0.4-360mAs
Dual focus Small focus: 0.6;Large focus: 1.3
Thermal capacity :900kJ(1200kHU)
The speed of the rotary anode :3000rpm
Grid:
Table Photography :103L /inch 15″x18″
Bucky Stand Photography :103L /inch 18″x18″
