The Basic Characteristics of the LED Film Viewer:
1. The power switch has Electric light to protect user for safe operation.
2. The viewing screen brightness is over 5000cd/㎡, improve the diagnosis quality of medical images and photographs. The Viewer has the advantages of low heat, cold light source, ultra-bright LED.
3. The screen brightness uniformity.The beads adapts equidistant lattice direct type light source layout, no brightness loss, no shadow between each screen.
4. According to the characteristics of human physiology, restricted to LED color temperature in white light 8800K region for the most suitable indoor observation. The color stability, no stroboscopic, reduce visual fatigue, protect the eyesight of doctor.
5. Observe screen uses the best acrylic sheet with best light transmission and diffuse scattering properties, no deformation, no color changing, durable.
6. Driven by a low voltage 12V DC power, safety, stability, reliability.
7. The frame is made of high quality molding aluminum alloy profile, has high-grade appearance.
8. Use the needle roller self-locking clamp device, clamp and take films fast and easy, no damage to the image picture.
9. Energy saving and environmental protection, long service life, high efficiency.
Technical Parameters:
Functional Parameters:
Screen quantity:Three Unit
Adjustable brightness :Yes
Adjustable brightness continuously on every Unit:Yes
Intelligent display the screen rightness values:Yes
Adjustable illuminated areas on every unit:Yes
Fast reset the maximum brightness and the maximum illuminated areas on every unit:Yes
Intelligent remember the screen brightness and the illuminated areas on every unit:Yes
Intelligent delay standby function:Yes
Intelligent switch function: insert automatically light up, pulling piece automatic extinguished on every unit:Yes
Electric light notice protection when boot electricity:Yes
Needle roller self-locking clamp device:Yes
Technical Parameters:
The light source type:Direct light source Led
Screen brightness (cd/㎡):The minimum brightness is 0 cd/㎡, The maximum brightness is over 5000 cd/㎡.
Screen dimensions (Length x height)(mm):1080×420
external dimensions (Length x height)(mm): 1136×493
Maximum power(V.A): 90
Maximum weight (kg): 7.8
