MSL Electrosurgical Generators & Monitors MSLEK06 for sale

Electrosurgical Generators & Monitors MSLEK06



MSL Electrosurgical Generators & Monitors MSLEK06 Features

Maximum output power: 150W

Four output modes: (1) pure cut, (2) mixed cut 1, (3) mixed cut 2, (4) electrocoagulation 1;

Electric cut mode: pure cut 100% cut, mixed cut 1 70 % cut, 30% coagulation; mixed cut 2 50 % cut,

50% coagulation;

Pure cut: Maximum output power 150W, enabling easy surgery on any tissues and structures;

Mixed cut: Applicable for any tissue, good coagulation effect when conducting cutting;

Electrocoagulation: Applicable for general open surgery and fine surgical point coagulation, featuring

deep tissue coagulation layer and excellent coagulation effect;

Panel operation: Overall microcomputer automatic control, two-zone (LED) digital display, key power

settings, waterproof panel design

Automatic adjustment: Automatically fine adjust power in a certain range to ensure the consistency

of the cutting effect;

Automatic recognition: Neutral unipolar/bipolar plate automatic recognition, when using the dual-circuit

plates and the contact area less than 60%, it should automatically stop the power output and send

sound-light alarm until the contact area returns to normal, which could effectively avoid burning patients by plates.

Application range：Used in gynecological, orthopedic, anorectal, general surgery, etc





Cheap Electrosurgical Generators & Monitors MSLEK06 Technical parameters



Safety standard

I-type BF-type

Ambient temperature range

+10℃~ +40℃

Relative humidity range

30~75%

Atmospheric pressure

700~ 1060 hPa

Power supply

220V ± 22V    50Hz  ± 1Hz

Operating frequency

530KHz±2

Load: Monopolar cut coagulation 300Ω

Rated output power

a)Pure cut: 1W ~ 150W（Peak voltage 1000V）

b)Mixed cut 1: 1W ~ 120W（Peak voltage 1500V）

c)Mixed cut 2: 1W ~ 100W（Peak voltage 2500V）

d)Electrocoagulation 1 :1W~100W（Peak voltage 3500V）

Overall energy consumption

≤1400VA

　

Transport and storage

a)Ambient temperature range: -40℃~ +55℃

b) Relative humidity range: ≤93%

c)Atmospheric pressure range: 500hPa ~1060hPa

　





Best Electrosurgical Generators & Monitors MSLEK06 Standard configuration sheet



1 host

2 electric knives

5 disposable neutral plates

1 neutral electrode connecting

1 power line

1 medical foot switch





Reusable ESU Pad for Electrosurgical Unit

Compatible with electrosurgical generator, radio frequency generator and other high frequency equipment.

The material is non-cytotoxic, without stimulus and sensitivity.

Neutral electrode cable : 3m





Disposable ESU Plate for Adult

Excellent adhesive and conductance.

Compatible with electrosurgical generator, radio frequency generator and other high frequency equipment.

The material is non-cytotoxic, without stimulus and sensitivity.





Best Durable Disposable Grouding Pads for Adult

Excellent adhesive and conductance.

Compatible with electrosurgical generator, radio frequency generator and other high frequency equipment.

The material is non-cytotoxic, without stimulus and sensitivity.





ESU Neutral Plate Cable

Compatible with electrosurgical generator, radio frequency generator and other high frequency unit.

Patient Plate cable : 3m.





ESU Bipolar Forceps

High precision, tissue preserving preparation instrument

Stainless steel , Titanium, and Non-stick

Stronger tension of the forceps allows for tissue spreading and dissection

A variety of patterns, lengths and tip size: Straight/ Bayonet forceps

Specialty forceps available for specific electrosurgery needs

Total Length:110mm/195mm/220mm for choice

Tap Connector: Europe Standard /America Standard/ Aesculap Standard

Different Color: Black/Blue/Yellow/Gray











Single Pedal Footswitch for Medical Equipment

Comfortable design and light weight.

Single pedal /double pedal control.

Compatible with ERBE/Vallylab/Martin and other brand electrosurgery unit.

The material of pedal is ABS.

Length of cable : 3m.





High End Double Pedal Electrosurgical Unit Footswitch

Comfortable design and light weight.

Single pedal /double pedal control.

Compatible with ERBE/Vallylab/Martin and other brand electrosurgery unit.

The material of pedal is ABS.

Length of cable : 3m.





Single Pedal Footswitch for Medical Equipment

Single pedal /double pedal control.

Compatible with ERBE/Vallylab/Martin and other brand electrosurgery unit.

The material of pedal is ABS.

Length of cable : 3m.





Waterproof ESU Footswitch for Surigical Instruments

Single pedal /double pedal control.

Compatible with ERBE/Vallylab/Martin and other brand electrosurgery unit.

The material of pedal is ABS.

Length of cable : 3m.





Reusable Hand Control Electrosurgical Pencil for Electrosurgical Unit

Hand control/foot Control color marked button

Hexagonal electrode connection

Length of cable : 3m

Banana connector(one-pin or three-pin)

Length of stainless steel blade : 24 cm

Length of ABS handle : 160mm

Function: cutting & coagulation





Reusable  Medical Supplies Electrosurgical Pencil

Hand control/foot Control color marked button

Hexagonal electrode connection

Length of cable : 3m

Banana connector(one-pin or three-pin)

Length of stainless steel blade : 24 cm

Length of ABS handle : 160mm





Hand Control Electrosurgical Pencil

Hand control/foot Control color marked button

Hexagonal electrode connection

Length of cable : 3m

Banana connector(one-pin or three-pin)

Length of stainless steel blade : 24 cm

Length of ABS handle : 160mm
