PC based ultrasound device MSLPU30 Technologies

* DBF: Digital Beam Forming

* RDA: Real-time dynamic aperture imaging

* DRA: Dynamic real-time acoustic apodizer

* DRF: Dynamic receiving focus

* DFS: Dynamic frequency scanning frequency range:2.0-12.0Mhz, 4 kinds of scaning frequenies

MSLPU30 LCD display and CRT display optional

CRT display

LCD display

PC based ultrasound device MSLPU30 Advantage

* Embedded computer platform is adopted in the ultrasonic master system

* THI

* DFC: Dynamic frequency scanning

* Histogram, Sectionl drawing, Puncture guide

* Save hundreds of thousands of images and cine loop permanently

* Dynamic real-time PIP local zoom functions

* Double connectors

* Double USB ports

* Multiple kinds of OB. measurement reports, fetus physiological grades and reports and fetus growth curve.

* Auto-create report systems of Gyn., small organs, cardiac, urology and other sections

* Compatible of jet printer, laser printer, video printer and video recorder

PC based ultrasound device MSLPU30 Excellent Diagnostic photos

* Display mode: B, 2B, 4B, B/M, M

* Image precess technologies: controllable frame correlation, Gamma correction, edge enhancement, image smoothing, image denoisiong, automatical gain adjustment, up/down, left/right and black/white conversation

* Dynamic Range: 100Db, 4 steps of switches

* Image magnification, stepless magnification, dynamic real-time PIP local zoom functions

* Cine loop: 512 frame auto/manual cine loop; multi screens cine loop (4B, 9B); auto/manual cine loop under B/M and M mode

* Image management system: the functions of pigeonholing, browsing, comparing, saving, printing and transferring images; as many as hundreds of thousands of images and thousands of cine loop could be saved; saved images could be operated by full-screen browse under slide mode.

3D full digital laptop ultrasound scanner MSLPU30 Relative extended ports

* VGA, S-Video, TV video port

* USB2.0 port, 2G saving card

* RJ-45 network port

* Multiple kinds of saving modes are all supported, containing soft disk, hard disk, falsh disk, CF card, SD card and others.

* Compatible of jet printer, laser printer, video printer and video recorder

PC based ultrasound device / desktop USG MSLPU30 Software Functions

* Measurement and calculation: measure perimeter and area by distance or ellipse method; measure perimeter and area by track method; measure body surface area and volume by ellipse method. 4 measure sticks; rate measure; linear stenosis ratio, area stenosis ratio, angle measure. All calculations are automatic.

* Assist tools: puncture guide, histogram, sectionl drawing

* Menu manage interface, real time online support and navigation clew system, image fore-set and one-key optimization functions

* Auto-measure software of OB., Gyn., small organs, cardiac, urology and others:

* OB.: BPD, CRL, GS, HA, AC, HC, FL, APAD, TAD, FTA, HUMERUS, OFD, THD, TIBIA, ULNA, FI, LIMP, BBT, FBP

* Gyn.: uterus diameter, intima thickness, ovary colume, regnant ovarian follicle, length of cervix long-diameter, uterine.

* Small organs: thyroid gland, hip joint.

* Cardiac: AOD, LAD, IVSTd, LVIDd, AA, LAD/AOD, LVPWd, LVIDs, EF, EF SLP,  CA/CE, MVCF, CO, CI, LVMWI, AVSV, FS, ACV, ET, SV, SI, LVMW, QMV.

* Urology: remained urine sample, prostate,PSAD.

* Presetting system for diagnosis and measurement formulas. Different formulas could be set according to different races.

* Patient cases database systems. All the data could be saved, searched and managed.

* Multiple kinds of OB. measurement reports, fetus physiological grades and reports and fetus growth curve.

* Auto-create report systems of Gyn., small organs, cardiac, urology and other  sections.

Full digital protable ultrasonic MSLPU30 Standard Configuration:

* Main unit

* 10.4 inches SVGA high resolution non-interlaced monitor

* 512 frame auto/manual cine loop; multi screens cine loop (4B, 9B); auto/manual cine loop under B/M and M mode

* Two probe connectors

* Two USB ports

* 3.5MHz R60/R50 electronic convex transducer(2.0/5.0MHz)
