chison i8
Digital Color Doppler System Datasheet
V1.0
March 28, 2014
ultrasonido abdominal chison i8 Dimensions and Weight
* Dimensions of main unit (approx.):825mmx519mmx1458mm
* Net weight of main unit (approx): 90kg (no probe included)
Electrical Power
* Power supply voltage: Auto adaptable for AC100V-240V
* Power supply frequency: 50-60 Hz
* Power consumption: 600 VA
General
Information
ultrasonido abdominal chison i8 Operation Panel
* Control panel
* Alphanumeric keyboard
* 8 TGC Slides
* Interactive backlit keys
* High resolution color LCD
– Diagonal dimension: 19 inch
– Resolution: 1280X1024
– Brightness adjustment
* Integrated speaker
– Volume adjustable
User
Interface
ultrasonido abdominal chison i8 Applications
* Abdomen
* Gynecology
* Obstetrics
* Urology
* Small Parts
* Pediatrics
* Vascular
* Musculoskeletal
* Cardiac
Scanning Method
* Electronic convex
* Electronic linear
* Electronic micro convex
* Electronic phased array
* Volume convex
Transducer Types
* 3.5MHz Convex transducer: D3C60L
* 7.5MHz Linear transducer: D7L40L
* 7.5MHz Linear transducer: D7L60L
* 12.0MHz Linear transducer: D12L40L
* 6.0MHz Trans-vaginal transducer: D6C12L
* 7.5MHz Trans-vaginal transducer: D7C10L
* 3.0MHz Micro convex transducer: D3C20L
* 5.0MHz Micro convex transducer: D5C20L
System
Overview
* 6.0MHz Micro convex transducer: D6C15L
* 3.0Mhz Phased array transducer: D3P64L
* 6.0Mhz Phased array transducer: D6P64L
* 4.5MHz 4D volume transducer: V4C40L
Image Modes
* B mode
* 2B mode
* 4B mode
* B/M mode
* M mode
* THI mode
* B/BC mode
* CFM Mode(Color Flow Mapping)
* Pulse Doppler
* CPA (Power Doppler)
* DPD (Directional Power Doppler)
* Multiple Compound Imaging
* SRA( Speckle Reduction Algorithm
* i-Image
* Trapezoidal imaging (only for linear transducer)
* Curved Panoramic Imaging
* 2D Steer
* Super needle
* Elastography
